- Product name：Liquid sachet pouch packing machine
- Model No：ADBZ-C60Y
- Features：
Product Description This liquid packing machine suit for automatic packaging of liquid of foods, medicine and chemicals, such as pesticide, shampoo, body foam bath lotion, facial cream, ingredient oil, fruit sauce, tomato ketchup and honey shower gel, skin lotion, toothpaste, cosmetic cream, fruit jam, edible oil, soy etc.
Product specifications
Main parameters of the machine
Model
ADBZ-C60Y Liquid sachet pouch packing machine
Product
Liquid
Measurement
Piston Pump
Hopper capacity
20L
Measuring range(one machine have one range for free, extra need to purchase)
1.7-3.2ml/3-6.5ml/4.7-7.8ml/3.8-10.1ml/6-12.4ml/9.5-16.9ml/13.3-23.9ml/19.2-35.6ml/27.5-51.8ml/47-82ml
Film width (Bag former)
40-240mm
Bag width
15-110mm
Bag Length
L:30-210mm (If special order can do 250mm)
Packing speed
15-60bags/min
Power Specifications
220V,50/60HZ, Single Phase
Shape of the seal(One machine do one sharp sealing)
back sealing, three side seal, four side seal (One machine do one sharp sealing)
Transverse sealing form
horizontal seal net pattern(1.2mm)
Cut off form
zigzag cutting or flat cutting (choose one)
Pull bag way
step motor
Weight
210kg
Overall dimensions
(L)640*(W)700*(H)1580
Packaging film
Laminate film
Remark
Mechanical Type
