- Product name：automatic tube filling and sealing machine
- Model No：AD-60
- Features：
Product Description 1. Compact design and auto tube feed. Driving part fully-closed. 2. Tube washing and feeding marking identification, filling, folding, sealing, coding printing and finished tube output all conducted by a fully automatic control system. 3. Tube washing and feeding conducted pneumatically, accurate and reliable.
Product specifications
Main parameters of the machine
Data sheets
Details
Name and model
AD-60 automatic tube filling and sealing machine
Max filling speed
2400-3000pcs/hour
Applicable tube diameter size
Φ10≤D≤Φ50mm
Applicable bottle height size
50≤H≤200mm
Filling accuracy
±1ml
Voltage
AC380 or AC220V, 50/60HZ
Power
7KW
Working pressure
0.6MP
Hopper volume
40L
