Product name:Semi-automatic weighing filling machine
Model No:AXGZ-SC-1
Features:
Product Description 1. Net weight filling, eliminating the error caused by tare weight and specific gravity 2. Two-stage (three-stage) automatic filling method with high accuracy. 3. The filling target is freely set to facilitate various weight packaging. 4. The filling machine is inserted and inserted to avoid the material splashing on the barrel. 5. When the filling target value arrives, the filling gun is automatically lifted. 6. When the filling gun is not inserted into the barrel, the tip is automatically lifted. 7. Unique anti-drip device to prevent material from dripping on the barrel. 8. The nozzle and the pipe adopt quick connector, which is convenient for washing and unloading. 9. The system is made of PLC, which is safe and reliable. 10.One-click filling, easy to operate.

Product specifications

Main parameters of the machine

Data sheets

Details

Name and model


AXGZ-SC-1    Semi-automatic weighing filling machine

Filling volume

10-200kgs

Filling Speed

B/min

40-60 barrels / h (depending on flow rate and pulse force)

Accuracy

0.1%

Net weight

100kg

Gross weight

140kg

Required air

0.4-0.8Mpa

Oversize(L*W*H)

2750*950*1700(mm)
