- Product name：Powder sachet pouch packing machine
- Model No：ADBZ-C60F
- Features：
This powder granule packing machine is suitable for ultra-fine powdery materials. Such as: milk powder, coffee powder, seasoning powder, milk tea powder, protein powder, bean powder etc. According to customer needs, the bag types can be changed：back seal, three sides seal, four side seal.
Product specifications
Main parameters of the machine
Model
ADBZ-C60F Powder sachet pouch packing machine
Product
Powder
Measurement
Screw feeding
Hopper capacity
10L
Measuring range(one machine have one range for free, extra need to purchase)
1-5ml/5-10ml/10-20ml/20-50ml/50-80ml/80-100ml
Film width (Bag former)
40-240mm
Bag width
15-110mm
Bag Length
L:30-210mm (If special order can do 250mm)
Packing speed
15-60bags/min
Power Specifications
220V, 50/60HZ, Single Phase
Shape of the seal(One machine do one sharp sealing)
back sealing, three side seal, four side seal (One machine do one sharp sealing)
Transverse sealing form
horizontal seal net pattern(1.2mm)
Cut off form
zigzag cutting or flat cutting (choose one)
Pull bag way
step motor
Weight
210kg
Overall dimensions
(L)640*(W)700*(H)1580
Packaging film
Laminate film
Remark
Mechanical Type
