- Product name：Semi Auto Liquid Filling Machine
- Model No：ADY series
- Features：
Product Description 1. High filling accuracy 2. Adopting SUS304 or SUS316L stainless steel 3. Fully pneumatic control 4. Easy operation easy cleaning 5. Ideal for liquid and liquid filling with low viscosity
Product specifications
Main Technical Parameters ：
Model detail
ADY-1-500K
ADY-1-1000K
ADY-1-2500K
Filling volume
50-500ml
100-1000ml
200-2500ml
Filling Speed
（B/min）
0-40
0-40
0-40
Accuracy
1%
1%
1%
Net weight
28kg
30kg
35kg
Gross weight
38kg
40kg
45kg
Volume weight
80kgs
80kgs
80kgs
Oversize (mm) (L*W*H)
1200*500*500
1200*500*500
1200*500*500
Required air
0.55Mpa~0.65Mpa
