- Product name：Automatic gravity liquid filling machines
- Model No：AXGZ-SZ
- Features：
Product Characters: 1. This filling machine is applied to liquid filling. 2. Especially suitable for water-based liquid . 3. Adopting Siemens PLC and easy operation display. 4. Adopting computer time control system 5. Adopted stainless steel (SUS304) 6. Easy set filling volume on display Application: This type of filler is best suited for liquids with very thin viscosities that do not change with ambient temperature or with batch variation. This machine is also suited for applications where re-circulation of the liquid in the fluid path is not desirable. Although this type of filler is used predominantly on products that do not foam, foam may be limited and controlled by subsurface/bottom-up-fill capability. Examples: Water, solvents, alcohol, specialty chemicals, paint, inks, corrosive chemicals i.e. acids and bleach. Advantages: This is the most economical type of filling machine for a limited range of applications. It is especially well suited for corrosive chemicals.
Product specifications
Main Technical Parameters ：
Data sheets
Details
Name and model
AXGZ-SZ-6
AXGZ-SZ-6B
AXGZ-SZ-8
AXGZ-SZ-8B
AXGZ-SZ-12
AXGZ-SZ-12B
Max filling speed (pcs/hour)
1000~2000
1600~2400
3000~3500
Power (KW)
0.8
0.8
1.0
Net/gross weight (Kgs)
400/500
400/500
500/600
Applicable bottle diameter size
Φ20 ≤D≤Φ100mm
Applicable bottle height size
30≤H≤300 mm
Filling accuracy
Filling 80ml-200ml accuracy: ±2ml
Filling 200ml-1000ml accuracy: ±1%
Voltage
AC220V, single phase, 50/60HZ
Working pressure
0.6MP
Air consumption
700L one hour (speed 2000 bottles/hour)
Machine size(L*W*H)
2000*1200*2100mm
Machine direction
From left to right
Operation process
Put products on conveyor—>Block bottles—> sensor count the empty bottles—> bottles come into the filling station —>lock bottles —>starting filling —> filling finished —> loose Block bottles—> Output bottles
